☀️ 37kW Solar VFD for Industrial-Scale Water Pumping
The CG Emotron VSR48075 is a 37kW solar pump inverter engineered for commercial and industrial irrigation projects. With 99% MPPT efficiency, it maximizes energy output from solar arrays, ensuring optimal performance in large pumping systems.
It supports AC and DC inputs, offers full motor protections, and operates intelligently in harsh, off-grid environments. Ideal for big farms and remote water supply projects.
⚙️ Technical Specifications:
-
🔧 Motor Power: 37.0 kW
-
☀️ Recommended Solar Array: 52–55 kWp
-
🔌 Max DC Input Current: 100 A
-
🔌 Output Current: 75 A
-
📐 Dimensions (mm): 322 x 226 x 220
-
⚖️ Weight: 10.6 kg
⚡ Input & MPPT Control:
-
🌞 DC Input Voltage Range: 230–800 VDC
-
🌞 MPPT Operating Range: 450–600 VDC
-
📈 Recommended Voc: 600–700 VDC
-
🌟 MPPT Efficiency: 99%
🌟 Key Features:
✅ Ultra-Efficient MPPT Control – Delivers peak energy performance
✅ 200% Overload – Reliable during surge or startup conditions
✅ Dual Input Flexibility – Works with solar and grid sources
✅ Smart Light-Based Operation – Auto sleep/wake modes
✅ Heavy-Duty Motor Protections – Thermal, stall, dry run, overload
✅ LCD Monitoring – Real-time diagnostics and performance display
✅ RS485 Modbus – Remote monitoring & control ready
✅ Rugged Design – Built for heat, dust, and moisture resistance
🌍 Best Applications:
-
🌾 Commercial Farming and Irrigation
-
🚜 Solar-Powered Borewells
-
🏭 Industrial Water Transport
-
💧 Rural & Off-Grid Pumping Infrastructure
🛠️ Why Choose VSR48075?
The CG VSR48075 is a powerful and reliable solar drive crafted to perform in heavy-duty pumping applications. Designed with durability and performance in mind, it’s the ideal solution for large-scale solar pumping systems.
