☀️ Powerful & Efficient Solar Water Pumping Solution
The CG Emotron VSR48006 is a 3.7kW solar pump inverter designed to convert DC power from solar panels into reliable AC power for three-phase motor-driven water pumps. Ideal for off-grid irrigation, deep borewell pumping, and livestock water supply, it ensures maximum power utilization with 99% MPPT efficiency, even in fluctuating light conditions.
Smart automation, rugged construction, and flexible compatibility with both AC and DC inputs make it a favorite in agricultural and rural setups.
⚙️ Technical Specifications:
-
🔧 Motor Power: 3.7 kW
-
☀️ Recommended Solar Array: 5.5–6 kWp
-
🔌 Max DC Input Current: 14 A
-
🔌 Output Current: 6 A
-
📐 Dimensions (mm): 186.6 x 116 x 175
-
⚖️ Weight: 3 kg
⚡ Input & MPPT Control:
-
🌞 DC Input Voltage Range: 230 VDC – 800 VDC
-
🌞 MPPT Operating Range: 450–600 VDC
-
📈 Recommended Voc: 600–700 VDC
-
🌟 MPPT Efficiency: 99%
🌟 Key Features:
✅ 99% MPPT Efficiency – Real-time maximum energy harvesting
✅ Gentle Pump Startup – Extends motor lifespan
✅ 200% Overload Tolerance – Handles tough starts smoothly
✅ Hybrid Power Ready – Accepts both AC & DC inputs
✅ Intelligent Sleep & Wake – Optimized for sunlight variations
✅ Weatherproof & Dust-Resistant – Ideal for outdoor installations
✅ LCD Interface – Advanced display with real-time monitoring
✅ Comprehensive Motor Protection – Dry run, stall, thermal, and overload safeguards
✅ Modbus RS485 Communication – Remote control and monitoring support
🌍 Ideal Applications:
-
🌾 Solar-Powered Agricultural Pumps
-
🐄 Livestock and Farm Watering
-
🚰 Rural Borewells and Tube Wells
-
🏕️ Remote Irrigation Projects
-
💧 Sustainable Water Supply Systems
🛠️ Why Choose VSR48006?
Built by CG Emotron with industrial-grade reliability, the VSR48006 solar pump drive delivers unmatched performance in demanding environments. It’s engineered for farmers, communities, and water-focused projects aiming to harness solar energy effectively.
